IMS
SERIES


IMV
SERIES


TN SERIES SPECIFICATIONS TABLE

Model
Max.
Flow
GPM
Max.
Head
FT
Max.
Temp
°F
Max.
Visc
SSU
Max.
Spec
Grav.
Connections
x
Immersion
Depth
in
Wetted**
Materials
MOTOR DATA
Shp.
Wt.
Lbs
Overall
Dimensions
In.
Inlet
Outlet
HP
RPM
Volts
PH
Hz
Encl
TN-41-1/2-F
62
25
225
500
1.1
1" FPT
7
CI
1/2
1725
230/460
3
60/50
TEFC
60
19 x 9 x 11
TN43H-2-F
90
73
225
300
1.1
1 1/4" FPT
9 1/2
CI
2
3450
230/460
3
60/50
TEFC
90
24 x 9 x 11
TN53-3/4-E
100
30
225
500
1.1
1 1/8" FPT
9 1/2
CI
3/4
1725
115/230
1
60/50
TEFC
62
22 x 9 x 11
TN53-3/4-F
100
30
225
500
1.1
1 1 /4" FPT
9 1/2
CI
3/4
1725
230/460
3
60/50
TEFC
62
22 x 9 x 11
TN53H-3-F
100
90
225
300
1.1
1 1/2" FPT
9 1/2
CI
3
3450
230/460
3
60/50
TEFC
100
24 x 9 x 11
TN53HH-3-F
100
100
225
300
1.1
1 1/2" FPT
9 1/2
CI
3
3450
230/460
3
60/50
TEFC
100
24 x 9 x 11
TN63-1-E
140
26
225
300
1.1
1 1/2" FPT
10 1/8
CI
1
1725
115/230
1
60/50
TEFC
100
26 x 9 x 10
TN63-1-F
140
26
225
300
1.1
1 1/2" FPT
10 1/8
CI
1
1725
230/460
3
60/50
TEFC
100
26 x 9 x 10
TN73-1-1/2-F
180
27
225
300
1.1
2" FPT
10 1/8
CI
1 1/2
1725
230/460
3
60/50
TEFC
105
27 x 9 x 10
IMS08-E
10
20
225
500
1.1
1/2" FPT
1/2" FPT
N/A
CI, NR
1/8
3450
115/230
1
60
TEFC
17
6 x 6 x 7
IMSOE-F
10
20
225
500
1.1
1/2" FPT
1/2" FPT
N/A
CI, NR
1/8
3450
230/460
3
60/50
TEFC
17
6 x 6 x 7
IMS25-E
20
32
225
500
1.1
3/4" FPT
3/4" FPT
N/A
CI, NR
1/4
3450
115/230
1
60
TEFC
37
8 x 8 x 9
IMS25-F
20
32
225
500
1.1
3/4" FPT
3/4" FPT
N/A
CI, NR
1/4
3450
230/460
3
60/50
TEFC
37
8 x 8 x 9
IMS50-F
32
42
225
500
1.1
3/4" FPT
3/4" FPT
N/A
CI, AL
1/2
3450
230/460
3
60/50
TEFC
40
8 x 8 x 11
IMS75-F
43
51
225
500
1.1
1" FPT
1" FPT
N/A
CI, AL
3/4
3450
230/460
3
60/50
TEFC
51
8 x 8 x 12
IMS100-F
48
60
225
500
1.1
1" FPT
1" FPT
N/A
CI, AL
1
3450
230/460
3
60
TEFC
53
8 x 8 x 12
IMV08-E
10
20
225
500
1.1
3/8" FPT
5
CI, NR
1/4
3450
115/230
1
60
TEFC
15
12 x 5 x 5
IMV08-F
10
20
225
500
1.1
3/8" FPT
5
CI, NR
1/8
3450
230/460
3
60
TEFC
15
12 x 5 x 5
IMV25-E
20
32
225
500
1.1
1/2" F PT
6
CI, NR
1/4
3450
115/230
1
60
TEFC
31
15 x 7 x 7
IMV25-F
20
32
225
500
1.1
1/2" FPT
6
CI, NR
1/4
3450
230/460
3
60
TEFC
31
15 x 7 x 7
IMV50-F
35
43
225
500
1.1
3/4" FPT
8 1/4
CI, AL
1/2
3450
230/460
3
60
TEFC
41
18 x 8 x 8
IMV75-F
45
52
225
500
1.1
1" FPT
9 7/8
CI, AL
3/4
3450
230/460
3
60
TEFC
51
21 x 8 x 8
IMV100-F
50
60
225
500
1.1
1" FPT
9 7/8
CI, AL
1
3450
230/460
3
60
TEFC
51
21 x 8 x 8

Other seal configurations available for temperatures up to 350°F.
* Contact a Water Cooling Engineer for assistance in selecting
pumps for fluids over 500 SSU.
** Also available in All Bronze and 316SSS construction.
See page 5 for material legend.

Contact a Water Cooling Application Engineer for assistance in selecting pumps for fluids with specific gravity over 1.1.
Also available in TEFC and Explosion Proof.
